Autodoors re-defined
2
CONVENTIONAL MOTOR
The EvoDrive+ is a redefinition of the traditional automatic door
operator.
S
has developed a unique magnetic linear motor that uses
an electrically powered motor that instead of rotating, it produces a
linear force using magnetic fields to create thrust and movement.
N
LINEAR MOTOR
N
S
N
S
N
S
This reduces the number of mechanical parts required, which
results in a very compact and stylish 60 x 70 mm aluminium housing, a quieter and
smoother motion and a longer lifespan, combining the compact size of a manual door track, with the performance
and convenience of a normal automatic sliding door.
3
Aesthetic Design
Housed compactly in a sleek aluminium casing that measures only 60 mm x 70 mm in
cross-sectional area, the reduced dimensions of the EvoDrive+ takes up a fraction of
any other traditional automatic door operator. Its elegant unobtrusive design also
allows users to enjoy the safety and convenience of having an automatic entrance
without compromising on aesthetics.
Silence in Motion
4
Powered by magnetic fields rather than mechanical action, the friction is dramatically
reduced, which results in a smooth and silent movement. This makes the EvoDrive+
the ideal automatic door for use in private residences, hotels, care homes and other
internal applications where a silent environment is required.
Enhanced Safety
The EvoDrive+ is highly sensitive to resistance and obstacles. It can be connected to a
wide v
ariety of safety sensors and activation devices, or even set the door in low
energy mode. The operator complies with all regulations in force, including European
Standard EN16005 "Power operated pedestrian doorsets".
5
Low Maintenance
The absence of belts, pulleys, reduction gears and other mechanical elements commonly used in traditional automatic doors, reduces the need for frequent maintenance
and replacement parts. The EvoDrive+ is easy to install and commission, and will operate for its entire life at a very reduced maintenance cost.
Highly Versatile
The EvoDrive+ is so small and compact that it pairs stylishly with a variety of materials, ranging from glass to aluminium or timber, integrating perfectly in any kind of
environment. A piece of architecture for creative minds.
6
Variety of Applications
The discreet and elegant look of the EvoDrive+ combined with it's silent movement,
will fit in any project, such as:
HOTELS
PRIVATE HOMES
OFFICE PARTITIONS
HOSPITALS
CARE HOMES
RESTAURANTS
AIRPORTS
SMOKING ROOMS
7
8
10
1
2
1. POWER SUPPLY: 110 - 230 V AC 50-60 Hz
2. INPUT/OUTPUT MODULE - MASTER
3. LEAF TROLLEYS
9
4. LINEAR MOTOR
8
5. MAGNETS
6. MOTOR DRIVER
7. PARAMETER SETTING
8. ALUMINIUM HOUSING
9. ALUMINIUM COVER
10. SIDE COVERS
Conform to European Norms and Directives in Force
Directive 2006/42/EC: "Machinery Directive"
Directive 2014/30/EU: “Electromagnetic Compatibility (EMC)”
Directive 2014/35/EU: "Low Voltage Directive (LVD)"
EN 16005:2013/AC:2015: “Power operated pedestrian doorsets"
Adjustable Parameters
Opening Direction: Right or Left
Low Energy or Normal Mode
Opening Speed
Closing Speed
Hold Open Time
Push & Go
Push to Open / Push to Close
Reduced Opening
Main Technical Features
Motor Technical Features
Compact Aluminium Housing: 60x70 mm
Minimum Clear Opening: 750 mm (Drive length: 1.550 mm)
Maximum Clear Opening: 1.400 mm (Drive length: 2.850 mm)
Leaf Weight: Up to 80 Kg
Adjustable Opening Speed: 200 to 600 mm/s
Adju
stable Acceleration and Braking Curves: 200 to 800 mm/s2
Low Operating Noise: <50 dB
Power Supply: 230/110 V AC 50-60 Hz
Power Consumption: In operation 80 W / Peaks (0,5 sec) 180 W / Stand-by 4 W
Electric three phase AC motor: Type LSMPM (Linear Synchronous Motor with Permanent Magnets)
Tension: 24 V DC
Peak current: 7 A
Operating current: 3 A
Motor driver:
- Magnetic position feedback with 3 hall cells
- Motion control by means of a driver with field oriented control (FOC)
- Wireless communication via Bluetooth
70mm
4
6
7
9
5
60mm
3
Actual size
8-12
10
8-10
30
=
SV - EASY (8 to 10 mm)
SH = SLIDING DOOR HEIGHT
10
=
70
10
SH = SLIDING DOOR HEIGHT
40
60
=
SH = SLIDING DOOR HEIGHT
=
=
=
60
60
60
=
=
=
70
SH = SLIDING DOOR HEIGHT
=
10
10
ALUMINIUM LEAF (44 mm)
10
40
60
=
TWINS (8 to 12 mm)
SH = SLIDING DOOR HEIGHT
=
60
10
10
SH = SLIDING DOOR HEIGHT
10
10
WOODEN LEAF (40 mm)
FULL GLASS (8 to 12 mm)
70
70
44
70
8-12
30
TOP RAIL (8 to 10
mm)
70
8-10
30
1
2
3
5
4
11
1. INFRARED SENSOR
4. PUSH BUTTON
2. AUTOMATIC LOCK
5. REMOTE CONTROL
3. TOUCH-LESS SWITCH
6. PUSH&GO
When the sensor detects presence or movement, the
door activates. It can also be used as a safety device.
Blocks the door when the leaf is in closed position and
the operating mode is in Closed or Exit Only mode.
The door opens and closes by simply approaching your
handor elbow to the device.
Press to open and close the door. Optionally, press to
open, and press a second time to close.
Four operating modes: Auto / Open / Close / Exit Only
Receiver incorporated in the main control board
Pocked size transmitter - 12V DC battery.
Push the leaf or the door handle, and the door will
open automatically. Push-to-open & Push-to-close
also available.
12
Hotel ABBA - San Sebastián
Silk Restaurant - Madrid
Dubai Airport T2
Public Toilet Door System
We offer a customized solution for public toilets in restaurants, hotels, airports, etc. The Evo
Drive+ can be connected to
a wide range of sensors and indicators for a user friendly and touch-less experience, to improve hygiene and to help reducing the spread of virus.
BASIC VERSION
Outside
Activates the door
to open
OPTIONAL
COMFORT VERSION
Inside
1. Locks the door when closed
2. Unlocks and opens the door to exit
Outside
Activates the door
to open
Free / Vacant
light indicator
Inside
Safety Sensor
Key Switch
Locks / Unlocks Opens the door
Keeps the door open when
someone stands on the pathway
Unlocks and opens the door
from outside on an emergency
EvoDrive+
Left Side Opening
EvoDrive+
Right Side Opening
DL = SW+CW+(A1+A2)
A1
A1
A2
OH
D2
A1
D1
A1
D1
SW
D3
CW
TD
OW
DL
TYPES OF OPERATORS AND ACCESSORIES
CW
TD
EvoDrive automatic sliding door operator, single slide. Right opening
EvoDrive automatic sliding door operator, single slide. Left opening
EvoDrive automatic sliding door operator, double-leaf
Automatic lock, fail-safe
Remote control with 4 o
perating modes (additional units)
ACTIVATION AND SAFETY DEVICES
Touch-less switch
Wireless push button (white)
Activation and safety IR+MW sensor, OAM-DUAL T
Activation and safety IR sensor, OA-203C
D2
D2
D2
D3
A1
A2
D2
OW
SWL
SW
Part Numbers
69360001
69131010
69330004
69320001
OH
DL
OW
DL Drive Length
OH Opening Height
OW Opening Width
CW Clear Width
SW Width of Sliding Leaf
TD Travelling Distance
D1/D2 Overlap
D3 Finger Trap Protection
A1/A2 Header extension
SW
DL
61013121R
61013121L
61023121
69620004
69111005
A1
A1
OH
SW
LEGEND
DL = 2(SWL+CW)+(2A1)
DL = SW+CW+(A1+A2)
A2
A2
EvoDrive+
Bi-part Opening
CW
TDL
13
SWR
D2
TDR
A1
LEAF ADAPTORS
67630001
67640001
67622000
67625002
67625003
67625004
67625005
TIMBER leaf adaptor for 40 wooden leaf, with floor guide
ALUMINIUM leaf adaptor for 45 mm frame
TOP RAIL leaf adaptor for 8-10 mm glass, with floor guide
FULL GLASS leaf adaptor for 8-12 mm glass, with floor guide
TWINS leaf adaptor for 8-12 mm glass
, with floor guide
SV-EASY leaf adaptor. Clamps for 8 mm glass, with cover
SV-EASY leaf adaptor. Clamps for 10 mm glass, with cover
ACCESSORIES FOR TOILET MODE
69150001
69150002
69600001
BASIC toilet mode kit: 2 touch-less switches and I/O interface
COMFORT toilet mode kit: 3 touch-less switches, light indicator and I/O interface
Key switch
14
15
